New Type Full Hydraulic Cone Crusher
Get PriceFactory-direct Sale

Production Capacity72-1100t/h

Max Iutput Size60-326mm

Processing Material: stone, granite, quartz, basalt, mining ore, etc.

Email Us: sales@zdzg.com

Introduction of New Type Full Hydraulic Cone Crusher/Multi-cylinder Hydraulic Cone Crusher

1.This series of hydraulic cone crusher is the new type multi-cylinder hydraulic cone crusher produced by our company. It is specially designed to crush the material with medium and high hardness,such as basalt,stone,limestone,ore,etc.

2.It is developed based on the latest technology,which not only improves the crushing efficiency, but also meets the strict requirements of final product shape.

3.Compared with spring cone crusher,it has better performance.It can be used for primary/secondary/fine crushing in mining,quarry,construction industry and other fields.

4.Due to its optimized structure,hydraulic cone crusher is the ideal choice for stone and mineral crushing of different stages.

Advantages of New Type Full Hydraulic Cone Crusher/Multi-cylinder Hydraulic Cone Crusher

1.Large production capacity 72-1100t/h,full models for sale.

2.High crushing efficiency,excellent final product particle shape.

3.High automation,reliable performance.

4.Easy operation and maintenance,saving cost.

Technical Data

Model	Max. feeding size (mm)	Processing capacity（t/h）
ZDHP200	178	160~250
	132	145~250
	110	120~250
	100	108~210
	76	81~210
	60	72~210
ZDHP300	200	230~445
	180	200~445
	115	180~445
	105	160~220
	82	140~220
	60	120~220
ZDHP400	280	270~630
	170	243~630
	130	210~630
	115	162~370
	90	126~370
	68	104~370
ZDHP500	285	365~790
	190	328~790
	152	280~790
	130	202~450
	105	158~450
	75	122~450
ZDHP800	326	616~1100
	298	522~1100
	238	380~1100
	136	328~730
	102	270~730
	77	166~730
